Powerform 35

pi controls
  • Maximum resistance to rotation.
  • Suitable for use on single part and multi-part hoist reeving systems.
  • High fatigue life resulting from the unique compaction process.
  • Increased resistance to crushing. Recommended for multi-layer spooling operations.
  • Increased abrasion resistance resulting from the unique compaction process.
  • Optional plastic impregnation. (P) signifies full plastic impregnation of the rope.
  • Fully lubricated in manufacturing.
powerform6-img1
Powerform 35
Standard Characteristics Powerform® 35/35P
Compacted Yes No
■
Grade 1960 2160
■ ■
Finish Bright Galvanised
■ ■
Lay Direction Right Hand Left Hand
■ ■
Lay Type Ordinary Langs
  ■
Nominal Fill Factor 0.745
Turn value at 20% of Breaking force degrees/ ‘6d’ 0.2
Discard Criteria Refer to ISO 4309:2019

Warning: Powerform® 6/6P in Langs lay must only be used in applications where both ends are secured and are unable to rotate.

powerform35-img2
NOMINAL ROPE DIAMETER APPROX. MASS MINIMUM BREAKING FORCE
GALVANISED & UNGALVANISED
ROPE GRADE
      1960 2160
mm in kg/100m kN tonnes kN tonnes
  1/2 81.1 148 15.1 160 16.3
13   85.0 155 15.8 167 17.0
14   98.6 180 18.3 192 19.6
16 5/8 129 233 23.8 252 25.7
18   163 300 30.6 321 32.7
19 3/4 182 331 33.7 358 36.0
20   201 372 37.9 399 40.7
21   222 402 41.0 434 44.2
22   243 444 45.3 484 49.3
  7/8 249 453 46.2 490 49.9
24   290 531 54.1 572 58.3
  1 325 591 60.2 640 65.2
26   340 621 63.3 661 67.4
28   394 720 73.4 788 80.3
  1-1/8 411 748 76.2 810 82.6
30   453 827 84.3 904 92.2
32 1-1/4 515 944 96.2 1040 106
35 1-3/8 616 1120 115 1220 124
36   652 1190 121 1290 131
38 1-1/2 726 1330 135 1440 146
40   805 1450 151 1590 162
42   887 1490 151 1620 165
44   974 1620 165 1780 181
  1-3/4 994 1650 168 1800 183
46   1060 1770 180 1930 196
48   1160 1940 197 2120 216
50   1260 2080 212 2300 234
  2 1300 2150 219 2380 242
52   1360 2260 230 2450 249

* Mass per unit length of POWERFORM 35P increases by approx. 3%

Note: POWERFORM 35P is available on special request and prior confirmation.
           Rope Sizes and Breaking Force not shown in the standard table, may be available on request and prior confirmation.
